Cat6 FTP lan Cable
Product structure and application：
Structured cabling cable data transmission;Digital transmission, voice, data and video signals, meet the demand of high-end is especially suitable for all D link and five types of applications，inclufing ISDN，10M nethernet，100M high speed nethernet，Gigabit Ethernet，4/16Mbit/s Token-ring，TP-PMD/TP-DDI 125 Mbit/s,ATM 155Mbit/s。
Electrical specification：
All parameters based on the 100 meters;
DC impedance ：100ohms±15%,1MHz t~250MHz;
transmission delay：536ns/100m max.@250MHz;
Time delay difference：35ns max/100m;
capacitance：5.6nF/100m
DCR≤9.4Ω
NVP:68%
Physical Property：
Structured cabling cable data transmission;Digital transmission, voice, data and video signals, meet the demand of high-end is especially suitable for all D link and five types of applications，inclufing ISDN，10M nethernet，100M high speed nethernet，Gigabit Ethernet，4/16Mbit/s Token-ring，TP-PMD/TP-DDI 125 Mbit/s,ATM 155Mbit/s。
Electrical specification：
All parameters based on the 100 meters;
DC impedance ：100ohms±15%,1MHz t~250MHz;
transmission delay：536ns/100m max.@250MHz;
Time delay difference：35ns max/100m;
capacitance：5.6nF/100m
DCR≤9.4Ω
NVP:68%
Physical Property：
| CM/CMR | LSOH | |
| maximum tension | 110N | 110N |
| minimum bending radius | 25mm | 25mm |
| Mounting temperature | 0 to 60℃ | 0 to 60℃ |
| storage temperature | -20 to 75℃ | -20 to 75℃ |
| operating temperature | -20 to 60℃ | -20 to 60℃ |
